If your Baxi boiler has suddenly stopped working and is showing a fault code, it can be frustrating but these codes are actually designed to help you quickly identify what’s gone wrong. Each fault code corresponds to a specific issue, such as low water pressure, ignition problems, or temperature sensor faults.





Baxi Boiler Error Codes
On this page, you'll find a clear list of common Baxi fault codes and what they mean, so you can better understand the issue before calling an engineer.
Whether it’s a pressure problem, ignition failure, or sensor error, this guide will help you take the right next step, whether that’s a simple fix or getting in touch with us here at KCM Heating.
E Series Error Codes
E20 – Overheat or faulty sensor
Cause: The boiler has overheated or the temperature sensor is faulty.
Solution: Check the system for any blockages that may be restricting the flow of water. If the problem persists, the temperature sensor may need to be replaced by an engineer.
E28 – Flue thermistor fault
Cause: The flue thermistor has failed or is not functioning correctly.
Solution: The thermistor will need to be inspected and replaced if necessary. A professional engineer should handle this repair.
E50 – Hot water thermistor fault
Cause: The hot water thermistor has failed or is malfunctioning.
Solution: The hot water thermistor should be inspected and replaced if required by a qualified engineer.
E78 – Water pressure sensor fault
Cause: The water pressure sensor is not functioning correctly or is disconnected.
Solution: Check the water pressure gauge and top up the pressure if necessary. If the fault persists, the sensor may need replacing.
E1 Error Codes (Pressure & Sensor Issues)
E119 – Low water pressure (below 0.5 bar)
Cause: The system pressure is too low, typically below 0.5 bar.
Solution: Use the filling loop to increase the water pressure to around 1.0-1.5 bar. If the pressure keeps dropping, check for leaks in the system.
E133 – Ignition failure (gas supply issue or frozen condensate pipe)
Cause: The boiler has failed to ignite, possibly due to a gas supply issue, faulty ignition electrode, or a blocked condensate pipe.
Solution: Ensure the gas supply is turned on and the condensate pipe is not blocked (especially in cold weather). Reset the boiler and see if it ignites.
E168 – Power supply issue or system lockout
Cause: A problem with the power supply to the boiler or a faulty printed circuit board (PCB).
Solution: Check that the boiler is receiving power. If the issue persists, the PCB may need replacing by a professional.
E5 Error Codes (Fan & Airflow Issues)
E160 – Fan fault (possible fan failure or PCB issue)
Cause: The fan has failed or there is a blockage in the flue.
Solution: Check for any blockages around the flue or fan. If the fan is faulty, it will need to be replaced.
L Series Fault Codes (Lockouts & System Errors)
L1 – Overheat lockout
Cause: The boiler has overheated and locked out to prevent damage.
Solution: Reset the boiler. If it keeps locking out, check for any blockages or airlocks in the system that could be restricting water flow.
L2 – Ignition lockout (could be a gas supply issue)
L5 – System reset lockout (too many resets)
Cause: Too many unsuccessful reset attempts.
Solution: Wait for a few minutes before attempting to reset the boiler again. If the issue persists, contact an engineer to identify the underlying fault.
